Notes of ordering
In case of order please note the following hints:
- The scope of delivery of the autocollimators already includes a collimator and an eyepiece reticle, a bulb illumination (6V/6W, without transformer). Transformer or also other illuminations (LED illumination) can be ordered separately. Please specify the desired reticles when ordering!
- On request, the autocollimators can also be equipped with eyepieces of focal length 25 mm or 10 mm. Unless otherwise specified, the autocollimators include an eyepiece with a focal length of 14.7 mm.
- Unless otherwise specified, adjustment to infinite distance of the reticle image is performed at a wavelength of 525 nm. Adjustment to other distances or wavelengths is possible through the tube extension.
- In case of order you can specify either the part number of the desired product or/and the article description. The article description for autocollimators with straight viewing and variable focus adjustment is shown on the right.
